Cortex-M0 LPC1100系列微控制器
NXP's LPC1100L is the lowest-priced 32-bit MCU solution in the market, bringing higher value and ease-of-use than existing 8-/16-bit microcontrollers through unprecedented performance, simplicity, low power, and more importantly, dramatic reductions in code size for all 8-/16-bit applications. The LPC1100L series offers a seamless entry point for any 8-/16-bit customers looking to start with the scalable ARM architecture throughout their entire range of product development. Built around the new Cortex-M0 architecture, the smallest, lowest-power, and most energy-efficient ARM core ever developed, these MCUs are ideally-equipped for use in battery-powered consumer devices, smart meters, motor control, and more. Note: The LPC1100L series (comprised of LPC11xx/x02 products) is differentiated from non-L LPC1100 products by its lower power consumption and easy-to-use Power Profiles. Please refer to the datasheet and user manual for detailed information.
NXP LPC1100 系列是市場上最低價32位MCU解決方案,比現存的8/16位微控制器有更高的性價比,易用性更強。此系列產品性能優異,使用簡單,功耗低,更重要的是大大簡化了所有8/16位實際應用中的代碼。LPC1100系列提供了一個無縫接入點,任何8/16位的用戶都可以在整個產品開發過程中,使用ARM架構。基于Cortex-M0架構的LPC1100,體積達到最小,功耗最低,在電池供電設備、智能儀表、馬達控制等應用中是最理想的解決方案。
Key Features:
- ARM Cortex-M0 processor, 50MHz operation
- Superior code density and higher performance than 8-/16-bit MCUs
- Industry's lowest active power consumption with easy-to-use power profiles
- Provides an easy migration path to Cortex-M3
主要特性:
- ARM Cortex-M0 處理器,工作頻率 50MHz
- 比8/16位MCU有更好的代碼密度,更高的性能
- 帶有更易使用的電源部件,具有工業級最低的功耗
- 與Cortex-M3 結合便容易
LPC1100系列ARM選型表
Type number | fmax [max] (MHz) | FLASH (kB) | RAM (kB) | I/O pins | USB device | CAN | UART | I2C | SPI | ADC | Timers | PWM | Package name | PLL | VDD [min] (V) | VDD [max] (V) | CPU supply voltage (V) |
LPC1110FD20 | 4 | 1 | 16 | 1 | 1 | 1 | 5 | SO20 | |||||||||
LPC1111FDH20/002 | 8 | 2 | 16 | 1 | 1 | 1 | 5 | TSSOP20 | |||||||||
LPC1111FHN33/101 | 8 | 2 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1111FHN33/102 | 8 | 2 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1111FHN33/103 | 8 | 2 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1111FHN33/201 | 8 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1111FHN33/202 | 8 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1111FHN33/203 | 8 | 4 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1112FD20/102 | 16 | 4 | 16 | 1 | 1 | 1 | 5 | SO20 | |||||||||
LPC1112FDH20/102 | 16 | 4 | 14 | 1 | - | 1 | 5 | TSSOP20 | |||||||||
LPC1112FDH28/102 | 16 | 4 | 22 | 1 | 1 | 1 | 6 | TSSOP28 | |||||||||
LPC1112FHN24/202 | 16 | 4 | 19 | 1 | 1 | 1 | 6 | HVQFN24 | |||||||||
LPC1112FHN33/101 | 16 | 2 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1112FHN33/102 | 16 | 2 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1112FHN33/103 | 16 | 2 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1112FHN33/201 | 16 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1112FHN33/202 | 16 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1112FHN33/203 | 16 | 4 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1112FHI33/202 | 16 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1112FHI33/203 | 16 | 4 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1113FHN33/201 | 24 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1113FHN33/202 | 24 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1113FHN33/203 | 24 | 4 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1113FHN33/301 | 24 | 8 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1113FHN33/302 | 24 | 8 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1113FHN33/303 | 24 | 8 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1113FBD48/301 | 24 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1113FBD48/302 | 24 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1113FBD48/303 | 24 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1114FDH28/102 | 32 | 4 | 22 | 1 | 1 | 1 | 6 | TSSOP28 | |||||||||
LPC1114FN28/102 | 32 | 4 | 22 | 1 | 1 | 1 | 6 | DIP28 | |||||||||
LPC1114FHN33/201 | 32 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1114FHN33/202 | 32 | 4 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1114FHN33/203 | 32 | 4 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1114FHN33/301 | 32 | 8 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1114FHN33/302 | 32 | 8 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1114FHN33/303 | 32 | 8 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1114FHN33/333 | 56 | 8 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1114FHI33/302 | 32 | 8 | 28 | 1 | 1 | 1 | 8 | HVQFN33 | |||||||||
LPC1114FHI33/303 | 32 | 8 | 28 | 1 | 1 | 2 | 8 | HVQFN33 | |||||||||
LPC1114FBD48/301 | 32 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1114FBD48/302 | 32 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1114FBD48/303 | 32 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1114FBD48/323 | 48 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1114FBD48/333 | 56 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC1115FBD48/303 | 64 | 8 | 42 | 1 | 1 | 2 | 8 | LQFP48 | |||||||||
LPC11C12FBD48 | 50 | 16 | 8 | 40 | 1 | 1 | 1 | 2 | 8 | 5 | 13 | LQFP48 | Y | 1.8 | 3.6 | 3.3 | |
LPC11C14FBD48 | 50 | 32 | 8 | 40 | 1 | 1 | 1 | 2 | 8 | 5 | 13 | LQFP48 | Y | 1.8 | 3.6 | 3.3 | |
LPC11C22FBD48 | 16 | 8 | 36 | 1 | 1 | 1 | 2 | 8 | 4 | LQFP48 | Y | 1.8 | 3.6 | ||||
LPC11C24FBD48 | 32 | 8 | 36 | 1 | 1 | 1 | 2 | 8 | 4 | LQFP48 | Y | 1.8 | 3.6 | ||||
LPC11D14FBD100 | 5.00E+07 | 0 | 8 | 42 | 1 | 1 | 2 | 8 | 4 | LQFP100 | Y | ||||||
LPC11U12FBD48 | 50 | 16 | 6 | 40 | 1 | 1 | 1 | 2 | 1 | 4 | LQFP48 | Y | 1.8 | 3.6 | |||
LPC11U12FHN33 | 50 | 16 | 6 | 26 | 1 | 1 | 1 | 2 | 1 | 4 | HVQFN32 | Y | 1.8 | 3.6 | |||
LPC11U13FBD48 | 50 | 24 | 6 | 40 | 1 | 1 | 1 | 2 | 1 | 4 | LQFP48 | Y | 1.8 | 3.6 | |||
LPC11U14FBD48 | 50 | 32 | 6 | 40 | 1 | 1 | 1 | 2 | 1 | 4 | LQFP48 | Y | 1.8 | 3.6 | |||
LPC11U14FET48 | 50 | 32 | 6 | 40 | 1 | 1 | 1 | 2 | 1 | 4 | TFBGA48 | Y | 1.8 | 3.6 | |||
LPC11U14FHN33 | 50 | 32 | 6 | 26 | 1 | 1 | 1 | 2 | 8 | 4 | HVQFN32 | Y | 1.8 | 3.6 | |||
LPC11U23FBD48 | 50 | 24 | 6 | 40 | 1 | 1 | 1 | 2 | 4 | LQFP48 | Y | 1.8 | 3.6 | ||||
LPC11U24FBD48 | 50 | 32 | 8 | 40 | 1 | 1 | 1 | 2 | 4 | LQFP48 | Y | 1.8 | 3.6 | ||||
LPC11U24FBD64 | 50 | 32 | 8 | 54 | 1 | 1 | 1 | 2 | 4 | LQFP64 | Y | 1.8 | 3.6 | ||||
LPC11U24FET48 | 50 | 32 | 6 | 40 | 1 | 1 | 1 | 2 | 4 | TFBGA48 | Y | 1.8 | 3.6 | ||||
LPC11U24FHI33 | 50 | 32 | 6 | 26 | 1 | 1 | 1 | 2 | 4 | HVQFN32 | Y | 1.8 | 3.6 | ||||
LPC11U24FHN33 | 50 | 32 | 8 | 26 | 1 | 1 | 1 | 2 | 4 | HVQFN32 | Y | 1.8 | 3.6 |
